Steel Coil Motorized Transfer Trolley Agv For Industrial Heavy Load Material Handling

Product Categories

Henan Perfect Handling Equipment Co., Ltd.

Contact Now

Steel Coil Motorized Transfer Trolley Agv For Industrial Heavy Load Material Handling

Name: Steel Coil Motorized Transfer Trolley Agv For Industrial Heavy Load Material Handling
Brand: Automated Guided Vehicles
Price: 800 USD

China Steel Coil Motorized Transfer Trolley Agv For Industrial Heavy Load Material Handling wholesale

Brand Name : Automated Guided Vehicles

Model Number : Automated Guided Vehicles

Certification : CE ISO SGS

Place of Origin : Henan China

MOQ : 1

Price : Usd800-4000/set

Supply Ability : 30sets/week

Delivery Time : 20 work days after received balance payment

Packaging Details : Trap and wooden case

Product Name : 20t Steel Coil Automatic Guided Vehicle AGV for Industrial Heavy load Material Handling Transportation

Ground Clearance(mm) : 50-75

Motor Power : 1-15

Wheel Base(mm) : 1200-7000

Running Speed(m/min) : 0-25

Battery Capacity(Ah) : 180-600

Battery Voltage(v) : 24-72

Table Size : Customized

Type : Automated Guided Vehicles

Contact Now

Steel Coil Motorized Transfer Trolley Agv For Industrial Heavy Load Material Handling

This 20t Steel Coil Automatic Guided Vehicle AGV for Industrial Heavy load Material Handling Transportation is usually used at ship yard, plant and factory on the floor, certain production line. and the 20t Steel Coil Automatic Guided Vehicle AGV for Industrial Heavy load Material Handling Transportation could get power from the battery. The battery is installed inside the 20t Steel Coil Automatic Guided Vehicle AGV for Industrial Heavy load Material Handling Transportation. The 20t Steel Coil Automatic Guided Vehicle AGV for Industrial Heavy load Material Handling Transportation was developed to dramatically reduce the material handling requirements of cranes and fork trucks while providing quick, safe and smooth movement of materials and/or products through manufacturing facilities. Automatic Guided Vehicle construction is based on our world renowned die agv transfer carts and provides controlled movement of heavy and oversized loads such as dies, coils and work in progress. Our agv transfer cart is available in a number of configurations specifically designed to suit the needs of our customers.such as,warehouse storage, food or beverage, plastic, pharmaceutical, rubber industry customers etc.

Steel Coil Motorized Transfer Trolley Agv For Industrial Heavy Load Material Handling

Detailed of the 20t Steel Coil Automatic Guided Vehicle AGV for Industrial Heavy load Material Handling Transportation

Steel Coil Motorized Transfer Trolley Agv For Industrial Heavy Load Material Handling

Technical Parameter of 20t Steel Coil Automatic Guided Vehicle AGV for Industrial Heavy load Material Handling Transportation

Model		2t	20t	50t	100t	150t
Rated Load(t)		2	20	50	100	150
Table Size(mm)	Length(L)	2000	4000	5500	6500	10000
	Width(W)	1500	2200	2500	2800	3000
	Heigth(H)	450	550	650	900	1200
Wheel Base(mm)		1200	2800	4200	4900	7000
Rail Inner Gauge(mm)		1200	1435	1435	2000	2000
Wheel Diameter(mm)		270	350	500	600	600
Wheel Quantity		4	4	4	4	8
Ground Clearance(mm)		50	50	50	75	75
Running Speed(min)		0-25	0-20	0-20	0-20	0-18
Motor Power(kw)		1	2.2	5	10	15
Running time When Full Load		4.32	4	3.3	3.2	2.9
Running Distance for Once Charge(KM)		6.5	4.8	4	3.8	3.2
Reference Weight(t)		2.8	5.9	8	14.6	26.8
Recommended Rail Model		P15	P24	P43	QU100	QU100

Functions & Advantages of 20t Steel Coil Automatic Guided Vehicle AGV for Industrial Heavy load Material Handling Transportation

NOTES:

Equiped forward or backing driving;
Options for automatic control;
Capacity from 1 ton to 300 tons;
Fixed speed or variable speed capabilities;
On board charging is available if battery drives;
Flat deck or fixtures for transporting special payload;
Custom deck configurations may include lift, tilt, or rotate function;
Available safety equipment includes horn, lights, emergency stop, bumpers and detector;
The agv transfer cart can run on the C-form track or S-form track and L-form track;
Reduce labor cost and remove overtime or turnover cost;
Guarantee the safety of factory device;

Application Sites of 20t Steel Coil Automatic Guided Vehicle AGV for Industrial Heavy load Material Handling Transportation

The 20t Steel Coil Automatic Guided Vehicle AGV for Industrial Heavy load Material Handling Transportation is mainly applied in assembly line(ring production line,loop production line),metallurgy industry(steel lade),warehouse transport,ship industry(maintenance, assemcle,container transport),work piece transport in workshop,lathe transport,steel factory(steel billet,steel plate,steel coil,steel pipe,section steel structure),construction(bridge,simple building,concrete column,)petroleum industry(oil pump,sucker rod and parts),energy(polycrystalline silicon,generator,windmill),chemical industry(electrolytic cell,retort etc),railway(rail maintenance,rail welding,train tractor)to transfport heavy load material inside the warehouse or workshop.

Steel Coil Motorized Transfer Trolley Agv For Industrial Heavy Load Material Handling
