35t Lathe Carriage No Rail Steel Mill Battery Transfer Cart With Remote Control

Product Categories
Henan Perfect Handling Equipment Co., Ltd.
Contact Now

35t Lathe Carriage No Rail Steel Mill Battery Transfer Cart With Remote Control

Brand Name : PERFECT

Model Number : BWP

Certification : CE, SGS, ISO

Place of Origin : Xinxiang, China

MOQ : 1 Set

Payment Terms : L/C, T/T, Western Union

Supply Ability : 75 Sets per month

Delivery Time : 45 Days

Packaging Details : The body will be packed with tarp, and other parts will be packed with wooden cases.

Powered Source : Storage Battery

Operation Mode : Pandent and Remote Controller

Load Capacity : 1-200Ton/ Customized

Color : Yellow and Blue/Customized

Working Time : 6~7 Hours

Wheel Type : Polyurethane Coated Wheel

Safrty Device : Buffer, Alarm light, Emergency Stop Buttons

Special Function : Anti-Explosion, Heat-Resistant, Lifting, Dumpling

Parameter : 3000*2000*450

Warranty : 12 Months

Contact Now

35t Lathe Carriage No Rail Steel Mill Battery Transfer Cart with remote control

Introduction of Remote Control Transfer Table

The 35T workshop lathe carriage no rail transfer cart has been widely used for their utmost extent working flexibility. Due to there is no predefined pathway and can steer in any direction and can run on any kind of floor the workshop lathe carriage no rail transfer cart is very beneficial to bring the heavy duty where overhead cranes cannot reach. In short, the no rail transfer cart symbolizes the best method for all those appliances with delicate handling issues in limited space.
More importantly, operating easiness make the workshop lathe carriage no rail transfer cart immaculacy to meet the most important demands: where places are very limited and pathways are extremely constrained.The conception of each transfer cart is guided with a preliminary study about particular needs of user and consequent use occasions.

Product porpuse

The lathe carriage no rail transfer cart of Henan Perfect Handling Equipment Co., Ltd has a wide range usage in industries, manufacturing and die-making plants.The no rail transfer carts are essential handling machines to cranes lifting heavy loading at ground and the superior solution for material transferring.

Parameters

Model BWP-5t BWP-20t BWP-30t BWP-40t BWP-50t
Rated Load(t) 5 20 30 40 50
Impacted rated load(t) 5 20 30 40 50
Structure of Frame Steel plates welded, beam
thickness of the steel plate 8 14 14 16 16
Cart weight(t) 4.3 7.9 8.8 10 10.5
Max. wheel load (t) 2.8 5.6 7.7 10 12
Ground requirement Cement floor or Steel plate ground
Ground Clearance(mm) 50 50 50 50 50
Table size (mm) 3000*2000 4500*2200 5000*2200 5500*2300 6000*2300
Height of the whole cart (mm) 450 600 650 700 700
Wheel base (mm) 1500 1700 1700 1800 1800
Axles distance (mm) 2500 3900 4300 4800 5200
Turning radius (mm) 2501 3901 4301 4801 5201
Turning type Turning while driving with no stop
Control method for turning Control button
Turning structure Mechanical
Motor power (KW) 3.5 7 10 12 15
Wheel diameter (mm) 300 (4) 400 (4) 400 (6) 500 (6) 500 (6)
Wheel material ZG55+hydropurture
Running speed (m/min) 0-15 0-12
Brake principle Electric magnetic brake
Ground balance mechanical automatic adjustment
Operation method With wire or no wire
Battery model D-250 24pieces D-440 24pieces D-250 36pieces D-330 36pieces D-440 36pieces
Battery maintenance Free of maintenance
Charger's installation Installed on cart Split-type
Cart color Yellow and warning sign
Charger's function Automatic stop for obstacles
Radar control 3-0.3 m, Automatic stop for obstacles
Warning equipment Sound and light
Other functions Turning light, night light and power display

35t Lathe Carriage No Rail Steel Mill Battery Transfer Cart With Remote Control

After Service

  • Our commitment: The load bearing safety factor of the electric transfer car for sale is no less than 120%.
  • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.
  • 16 hours engineering service and 24 hours internet service for our customers.
  • During the warranty period, if our electric transfer car for sale can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.
  • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.

35t Lathe Carriage No Rail Steel Mill Battery Transfer Cart With Remote Control
