Customized battery-powered transfer car can carry 150-ton steel, wood in industry
Description
BXC series' battery powered transfer car---- it is powered by the storage battery, it is our specialized research, Simply speaking, it is an electric cart. Compared with BTL, It has no limited by distance; Compared with others, it is simple operation and structure, But its main source powered is the battery, so it has the limitation of time, and the storage should be maintained once a regular time, its lifetime reach to about 2.5 years. BXC series 'battery powered transfer car can be used in many occasions, due to its simple structure, wherever in the factory or assembly line, just exists track, and the battery is charged fully, it can transport anywhere. Compared with BTL, BJT, BDG, it is not so complicated. Compared with KPD, it is not so strict requirement. Therefore it is the reason why many buyers like to purchase it. It is popular in many foreign countries like South American, Germany, Turkey etc. Our company have a professional team and utilize more advanced technique to make it.
Advantages
Simple structure
Not subject to transportation distance
easy to use
Strong carrying capacity
Energy saving and environmental protection
Long battery life
Application
The battery-powered transfer cart is suitable for various industries, steel mill, steel structure, steel pipe, steel billets, steel ladle and coil, etc, transfer steel produce from one location to another.
Components
Technical parameters:
| Model | BXC-2t | BXC-5t | BXC-10t | BXC-16t | BXC-20t | BXC-25t | BXC-30t | BXC-40t | BXC-50t | BXC-63t | BXC-80t | BXC-100t | 150 | | Table Size(mm) | Length( L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 | | Width( W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | | Height( H) | 450 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | | Wheel Base(mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | | Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | | Wheel Diameter(mm) | Ф270 | Ф300 | Ф300 | Ф350 | Ф350 | Ф400 | Ф400 | Ф500 | Ф500 | Ф600 | Ф600 | Ф600 | Ф600 | | Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | | Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | | Running Speed(m/min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | | Motor Power(Kw) | 1 | 1.2 | 1.6 | 2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | | Battery Capacity(Ah) | 180 | 180 | 160 | 180 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | | Battery Voltage(V) | 24 | 36 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | | Running Time When Full Load | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 | | Running Distance for One Charge(Km) | 6.5 | 8.1 | 7.2 | 5.1 | 4.8 | 4.8 | 4.2 | 4.3 | 4 | 3.6 | 4.3 | 3.8 | 3.2 | | Max Wheel Load(KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | | Reference Weight(t) | 2.8 | 3.6 | 4.2 | 5.5 | 5.9 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 | | Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 | |
Successful case
Tianjin Huasaier Heat Transfer Equipment Co.Ltd purchased BXC-100T electric transfer cart. It is used in the sandblasting room. The sand-blast equipment diameter is 3m. The weight is from 20t-100t. The table size is 5mx3m and fixed with support roller to ensure all parts sandblasting. Battery powered transfer cart has low table, which successfully solved the problem of limited room. To protect motor, reducer and electric appliance, they do protection treatment. After using 3 years, the transfer cart still can work.
Main feature
Load: 2ton-150ton
Track: vertical track, L-form track, S-form track or curved track
Power: battery
Battery: 180-600
Motors: DC brush motor, DC brushless motor
Wheel size: customization
Number of wheels: 4
Table size: customization
Certificate show
