Raw Material Transfer Bogie Explosion Proof Warehouse Automated Handling Vehicle
Introduction of Explosion Proof Warehouse Automated Handling Vehicle
The explosion proof warehouse automated handling vehicle, literally speak, it is a industrial transfer cart without rails, which is the special type compared with traditional rail vehicle. More importantly, it has been new favorite in the industry transport field all over the world with hot market. Especially for the workshop that it exists unfixed running distance.
Moreover the explosion proof warehouse automated handling vehicle is our patented product. We research and develop this kind product to make the handling simple--this series automated handling vehicle, by contrast, has no need for steel rail installation and will not be restricted by the cable outside the vehicle. All in all, it make the working process promote efficiency, and its operation is simple. It is so popular in many countries, Like Germany, Turkey, Malaysia, Indonesia, Malaysia, Pakistan, South Africa and so on.
Application of Explosion Proof Warehouse Automated Handling Vehicle
Our explosion proof warehouse automated handling vehicle is suitable for various occasions:
Steel mill: Transfer steel products such as steel structure, steel pipe, steel billets, steel ladle and coil, etc from one location to another;
Paper roll plant: transfer paper coil
Painting shops: Transfer work piece into the painting room Sand blasting room) Other industries: Shipbuilding: Due to the large load capacity, the explosion proof warehouse automated handling vehicle is applied in ship industry to transfer workpieces, maintenance tools (propeller, motor etc.).
Quarries: Transport large mechanical include giant excavator, stone breaker etc
Warehouses: For material handling and storage
Multi-bay workshops: The explosion proof warehouse automated handling vehicle can be used to convey raw material or finished product betweent multi-bay.
For coal mine usage:
This series explosion proof warehouse automated handling vehicle has been widely used in this field with hot market. Any interests and problems, welcome to contact with us. The proper solution can be provided to you once getting for your confirmation.
Components of Explosion Proof Warehouse Automated Handling Vehicle
About the battery, we choose maintenance free which is convenient, and long lifetime, we needn't remove. so in this series warehouse automated handling vehicle, it is popular among customers.
About the wheels, which material is PU, inside is cast steel, outside is encapsulation. By this design, its main function is damping. Our electric transfer traverser is also used it.
Related Products
Parameters of Explosion Proof Warehouse Automated Handling Vehicle
| Model | BWP-5t | BWP-20t | BWP-30t | BWP-40t | BWP-50t |
| Rated Load(t) | 5 | 20 | 30 | 40 | 50 |
| Impacted rated load(t) | 5 | 20 | 30 | 40 | 50 |
| Structure of Frame | Steel plates welded, beam |
| thickness of the steel plate | 8 | 14 | 14 | 16 | 16 |
| Cart weight(t) | 4.3 | 7.9 | 8.8 | 10 | 10.5 |
| Max. wheel load (t) | 2.8 | 5.6 | 7.7 | 10 | 12 |
| Ground requirement | Cement floor or Steel plate ground |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 |
| Table size (mm) | 3000*2000 | 4500*2200 | 5000*2200 | 5500*2300 | 6000*2300 |
| Height of the whole cart (mm) | 450 | 600 | 650 | 700 | 700 |
| Wheel base (mm) | 1500 | 1700 | 1700 | 1800 | 1800 |
| Axles distance (mm) | 2500 | 3900 | 4300 | 4800 | 5200 |
| Turning radius (mm) | 2501 | 3901 | 4301 | 4801 | 5201 |
| Turning type | Turning while driving with no stop |
| Control method for turning | Control button |
| Turning structure | Mechanical |
| Motor power (KW) | 3.5 | 7 | 10 | 12 | 15 |
| Wheel diameter (mm) | 300 (4) | 400 (4) | 400 (6) | 500 (6) | 500 (6) |
| Wheel material | ZG55+hydropurture |
| Running speed (m/min) | 0-15 | 0-12 |
| Brake principle | Electric magnetic brake |
| Ground balance | mechanical automatic adjustment |
| Operation method | With wire or no wire |
| Battery model | D-250 24pieces | D-440 24pieces | D-250 36pieces | D-330 36pieces | D-440 36pieces |
| Battery maintenance | Free of maintenance |
| Charger's installation | Installed on cart | Split-type |
| Cart color | Yellow and warning sign |
| Charger's function | Automatic stop for obstacles |
| Radar control | 3-0.3 m, Automatic stop for obstacles |
| Warning equipment | Sound and light |
| Other functions | Turning light, night light and power display |
Packing & Shipping
The sexplosion proof warehouse automated handling vehicle for sale body is packed with tarp, the wheel and parts will be packed with wooden case.
For length is less than 5.9m, the width is less than 2.2m. It will be transported by 20ft container. If the length is longer than 5.9m and less than 12m, it will be transported by 40ft container. If the quantity is 2 sets or 3 sets, they can be transported by full container. If the quantity is 1 set, it can be transported by LCL Container. If the length is less than 12m, the width is beyond 2.2m. It needs to be transported by FR container (20 or 40 ft). If the automated handling vehicle for sale is beyond above dimension, it needs to be transported by BB container. Determine the size & material of the box according to the shape & number of products.
After Service
- Our commitment: The load bearing safety factor of the electric transfer car for sale is no less than 120%.
- Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.
- 16 hours engineering service and 24 hours internet service for our customers.
- During the warranty period, if our electric transfer car for sale can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.
- Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
Our Strength
Henan Perfect Handling Equipment Co., Ltd is a collection of research, design, manufacture, installation and after-sales service of handling equipments, as one of the professional manufacturing company, which has a modernized management team and excellent staff. And our prodcuts gets CE, SGS, ISO certificate and other 8 national patent, our products have been exported to more than 50 countries and regions, such as Germany, Mexico, USA, Turkey, South Africa, Singapore etc.
